FOV: 120×90°; wavelength 940nm; Lens size(mm) 2.6×2.6
$60.00
Discount per Quantity
| Quantity | 50 - 100 | 100 - 1000 | 100000 + |
|---|---|---|---|
| Discount | 0% | 20% | 97% |
| Price | $60.00 | $48.00 | $1.80 |
This product requires prior confirmation. Orders placed directly without contacting us in advance cannot be processed.
10000 in stock
| Wavelength
unit:nm |
FOI（HxV）
unit:deg |
Lens Size
（HxV） unit:mm |
Recommended Number of Emitting apertures | Dot-Matrix Replication Counts（HxV） | Total Dot Counts | Far-Field Divergence Angle unit：deg | Transmittance | Overall Efficiency | Current Status | Mass-Production Delivery Timeline | |
| MCPD357940 | 940 | 120×90 | 2.6×2.6 | 221 | 43 | 9503 | 0.26 | 67% | 62% | In Mass Production | One Month After MP PO |
| Specification | |
| Device Parameters | |
| Model | MCPD357940 |
| Material | Si, SiO2 |
| Thickness | 0.775 mm (±0.015) |
| Lens Size (H×V) | 2.6×2.6 mm (±0.025) |
| Active Metasurface Area (H×V) | 2.3×2.3 mm (±0.001) |
| BFL1 (Metasurface Facing Source) | Contact us for further details |
| BFL2 (Metasurface Facing Away from Source) | Contact us for further details |
| Dot-Matrix Replication Pattern (Periodic/Offset) | Offset arrangement |
| Replication Count (Spots per Single-Aperture emitting aperture) | 43 |
| Transmittance (Total Output/Input Energy) | ~67% |
| Overall Efficiency (Array Output/Input Energy) | ~62% |
| Operating Temperature Range | -40°C to 250°C |
| Far-Field Divergence Angle (Central Spot) | ~0.26° |
| Recommended Light Source | |
| Recommended emitting aperture Cavity Area (H×V) | Contact us for further details |
| Projection FOI (H×V) with the Recommended Light Source | Contact us for further details |
| emitting aperture Arrangement (Periodic/Offset) | Contact us for further details |
| Number of Emitting Cavities | Contact us for further details |
| Total Spot Count w/ Recommended Source | Contact us for further details |
